Mouse Sticky Paper Glue Machine / insect / rat Killer Paper Making Machine / pest Control Trap Forming Machine
Product Details
Pest Control Glue Machine
,Rat Glue Machine
,Insect Glue Machine
HG818 PLC Automatic Hot melt glue machine
1.Basic type (semi auto )
2.Automatic feed raw material
3.Automatic put glue in traps
4.40 kg glue tank
5.Max Glue coating size :150mm -230mm
6.Belt width size :350mm
7.Three scraping glue guns
8.Speed more than 3000pcs per hour
9. Use PLC control ,more automatic.
10.Add Horizontal folding device
(basic type machine has automatic feeder and automatic glue function,other process need manual for trap )
3.Machine Introduction
The hot melt glue machine can produce varies of sheet product ,it is include mouse rat glue trap ,flies trap .cockroach house trap , yellow sticky trap, cardboard mouse trap and plastic mouse trap etc .
a. Composition
The hot melt glue machine production line : (Basic type)
Automatic feed raw material device (Including)
Convey device(Including)
Put glue device (including)
Add transverse folding device for making mouse/fly glue board(optional)
Button device(optional)
Bait release device (optional)
Fold device (optional)
b. Working principle
The mouse paperboard raw material is placed on the automatic paper feeding device, which is sent out in a single sheet. after the glue application photoelectricity detects the mouse board on the conveyor belt, the glue gun falls to apply glue to the sticky mouse glue board , then manual pasting the release paper .
( If produce book type mouse board , it will manual put button and fold it instead of past the release paper by manual )
-
