Mouse Rat Glue Trap Making Machine With PLC Control System 60pcs/min
Product Details
Mouse Rat Glue Trap Making Machine
,PLC Rat Glue Trap Making Machine
,20L Rat Glue Trap Making Machine
Yellow Sticky Trap Rat Glue Trap Making Machine With Auto Feed
1.Rat Glue Trap Making Machine Description:
Our diverse hot melt glue machine has the ability to produce a myriad of sheet products including mouse andrat glue traps, fly traps, cockroach house traps, yellow sticky traps, cardboard mouse traps, plastic mouse traps.
As a respected provider of hot melt adhesives, our mainstream model delivers superior performance at competitive prices, making it a prudent choice for SMBs.
Its automatic feeding of raw materials and adaptability allow for a variety of raw material sizes.
The conveyor system features many elements, each contributing to the system operation.
Mount the glue device with basic components.
Optional equipment includes the device button, while a baitrelease device assists in dislodging hooks from fish.
In addition, using a folding device such as a tablet or smartphone allows for easy document opening.
2.Rat Glue Trap Making Machine Specifications:
| Glue coating machine | |||
| Item | Name | Unit | Qty |
| 1 | PT100 temperature control meter | pcs | 2 |
| 2 | Solid state relay(40A) | pcs | 4 |
| 3 | Fuse and its seat | set | 3 |
| 4 | Aviation plug(big,small) | pair | 1 for each |
| 5 | PT100 temperature sensing head | pcs | 3-4 |
| 6 | Return valve | pcs | 1 |
| 7 | Filter core(big,small) | pcs | 1 for each |
| 8 | Hose connector 45 | pcs | 4 |
| 9 | Sealing ring, gasket (including gear pump oil seal) | several | |
| 10 | Flat sealant | bottle | 1 |
| 11 | Filter | pcs | 1 |
| 12 | Polytetrahydrogen tube | meter | 1 |
| 13 | Copper sheet | pcs | 1 |
| 14 | Various types of screws | pcs | several |
| 15 | Glue gun body: (with thimble 4) | pcs | 1 |
| 16 | Gas joint | pcs | several |
| 17 | air tube | meter | 10 |
| 18 | Barometer (single , double ) | pcs | 1 for each |
| 19 | Plastic hose 1.8meters | pcs | 1 |
| 20 | Various switches | pcs | several |
| 21 | Intermediate relay(24V) | pcs | more than 4 |
| 22 | Various heating tubes | pcs | 2-3 |
| 23 | Chain (several joints ) | pcs | 1 |
| 24 | Photoelectric: ( silver , yellow) | pcs | 2 for each |
| 25 | Intermediate relay(220V) | pcs | more than 3 |
| 26 | Solenoid valve | pcs | 3 |
| 27 | Host belt | pcs | 1 |
| 28 | Hexagon wrench | set | 1 |
| 29 | Training Video CD | pcs | 2 |
| 30 | Hole punch tool | pcs | 1 |
| 31 | Reinforcement of gun seat and rubber tank filter | set | 1 for each |
| 32 | Various springs | pcs | several |
| 33 | Inverter panel | pcs | 1 |
| 34 | Square cylinder | pcs | 2 |
| 35 | Half-moon shape bearing | pcs | 1 |
| Auto feeder part | |||
| 1 | Feeder belt | pcs | 4 |
| 2 | Speed adjust meter | pcs | 1 |
| 3 | paper press wheel | pcs | 4 |
3.Rat Glue Trap Making Machine Feature:
Automatic Feeder, an advanced apparatus, caters to automatic animal feeding and productivity enhancements.
Dimensions: 92cmx83cmx111cm
Key Features: Paper feeding motor employs a 200 vertical motor, frequency converter adjusts speed, paper output stabilizes, and speed is modifiable, accommodating various fly sticker thicknesses, sticky mouse boards, roach houses, light boards, etc.
Hot Melt Glue Machine is a multi-use instrument aiding manufacturers and crafters in applying adhesive to assorted materials efficiently.
Dimensions: 96cmx48cmx109cm
Key Features: Melter motor harnesses a 750w three-phase motor, frequency converter alterations speed. 45cc gear pump, maximum glue capacity reaches 40g, heating power is 9kw, and heating duration is approximately 40 minutes.
The organization's primary production line focuses on assembling gluing machines, essential in the manufacturing process.
Dimensions: 228cmx96cmx110cm
Key Features: Main drive motor is a 750w three-phase motor with variable frequency speed control, conveyor belt operates swiftly and maintains stability, and PLC or time relay adapts various timing parameters. High precision sensor capable of sensing black or colored products simultaneously.
PLC + touch screen
Cylinder baffle (Anti- tailing device )
Function is anti tailing when applying glue.
-
