Semi Automatic Double Carton Box Stitching Machine Packing Machine
1,Carton Box Stitching Machine Description:
Carton Box Stitching Machine, specifically designed to automate the process of joining two or more cardboard boxes together to form a complete packaging unit, can ensure efficient production and packaging processes in any industry. These machines use a series of belts, rollers, and clamps to hold the boxes in place and apply pressure to the crease areas, resulting in a strong and seamless joint. This design can enhance the overall stability and durability of the packaging unit and reduce the chance of damage during transit or storage.
Carton Box Stitching Machines are versatile machines that can be used in a variety of industries including food and beverage, healthcare, and retail. In each of these industries, carton boxes are an essential component for packaging and transporting products, and the Carton Box Stitching Machine can improve efficiency, reduce labor costs, and increase productivity.
2,Carton Box Stitching Machine Specifications:
| 型号及参数 | SDJ-1600D | SDJ-2000D | SDJ-2500D |
| 最大纸张尺寸(A+B)＊2 (mm) Max.paper size | 3200 | 4000 | 5000 |
| 最小纸张尺寸(A+B)＊2 (mm) Mini paper size | 980 | 980 | 980 |
| 最大纸箱长 A mm Max carton length | 800 | 1000 | 1250 |
| 最小纸箱长 A mm Min carton length | 370 | 370 | 370 |
| 最大纸箱宽 B mm Max carton width | 800 | 1000 | 1250 |
| 最小纸箱宽 B mm Min carton width | 120 | 120 | 120 |
| 最大纸张高(C+D+C) (mm) Max paper height | 2500 | 2500 | 2500 |
| 最小纸张高(C+D+C) (mm) Min rock cover | 450 | 450 | 450 |
| 最大摇盖尺寸 C(mm) Max rock cover | 460(加长 560) | 460 | 560 |
| 最小摇盖尺寸 C(mm) Min paper height | 80(20 特殊说明) | 80 | 80 |
| 最大高度 D(mm) Max high | 2000 | 2000 | 2000 |
| 最小高度 D(mm) Min high | 200 | 200 | 200 |
| 最大钉舌宽度(mm) MAX width of the tougue | 40 | 40 | 40 |
| 钉 距 mm Nailing From | 30-150 | 30-150 | 30-150 |
| 给纸高度 mm Freeding high | 900 | 900 | 900 |
| 钉 数 Number of nails | 2-99 | 2-99 | 2-99 |
| 打 钉 速 度 (次/mim) Stitching speed | 600 | 600 | 600 |
| 机器重量(T) Weight | 3.2 | 3.5 | 3.8 |
3,Carton Box Stitching Machine Feature Advantage:
★ Mitsubishi Japan double servo drive,precision accuracy,mechanical transmission part is reduced,which can effectively reduce the failure rate of the machinery.
★ Nail box machine the whole control system adopts OMRON PLC control system.
★ The nail box machine control box contactor used in Germany Siemens brand.
★ The relay circuit breaker using French brand Schneider,photoelectric and proximityswitch with Japan’s OMRON brand.
★ The bottom die blade adopts Japanese tungsten steel production(wear)
★ The whole set of nail heads are made of Taiwan original parts, and the machine head has longer service life.
★ The transform carton size and adjusting nail carton from just one minute can be completed,greatly saves time and is convenient to operate.
★ The automatic nail box machine after the paragraph with the function of automatic counting,finished cartons can be set according to the number (2-99)sub stack sent to the conveying machinery terminal, convenient bundling.
