Auto Belt Paper Feed Thin Blade Slitter Scorer Machine Manual Adjust
Product Details
Manual Adjust Thin Blade Slitter Scorer Machine
,Auto Belt Thin Blade Slitter Scorer Machine
Auto Belt Paper Feed Thin Blade Slitter Scorer Machine Manual Adjust
Thin Blade Slitter Scorer Machine Description:
Thin blade slitter machines can be used on their own or in conjunction with other machines in a corrugated paper production line. They are highly specialized machines that are designed to slit corrugated paper into narrow pieces, while also creating a horizontal crease on the corrugated paper.
The importance of this machine for the production of corrugated carton boxes cannot be overstated.
Thin Blade Slitter Scorer Machine Specifications:
| Spec | Data |
| Machine allows cardboard width (width) | 2300mm |
| The maximum mechanical speed: | 150 m / min |
| Paper Cutter | (according to user requirements increase or decrease) 4 pieces |
| pressure line Round: | (according to user requirements increase or decrease) 6 pairs |
| Minimum slitting width: | 140mm |
| Minimum pressure line width: | 30mm |
| outer diameter of paper thin blade: | 200mm |
| paper thin blade thickness: | 1.3mm (alloy) |
|
Main motor power: Fan power: |
5.5kw 3.4kw |
| Air pressure: | <0.4mpa |
| Machine dimensions: | 3400 × 2300 × 1500mm |
| Weight: | 1600kg |
| Min.Feeding: | (two plastic wheelbase) 320mm |
Thin Blade Slitter Scorer Machine Feature Advantage:
Energy saving: The belt conveys the feed with less energy, which is more energy efficient than other feeding methods.
Space saving: The belt conveyor feed can realize the feeding in a limited space, saving a lot of storage space.
Efficient and stable: The belt conveys the feed at a fast speed and has good stability, which can ensure the continuity and accuracy of the feed.
Protect the cardboard: The belt conveys the feed to ensure that the load-bearing pressure of the cardboard remains unchanged and will not damage the corrugated structure.
Easy maintenance: The maintenance of belt conveyor feeding is relatively simple, only need to check and maintain the belt regularly.
Low noise: The belt transmission feed will not produce too much noise and will not adversely affect the surrounding environment.
Low cost: The cost of belt transmission and feeding is relatively low, which is suitable for large-scale production.
