1400mm 5 Ply Corrugated Board Production Line Electrical Mill Roll Stand

1400mm 5 Ply Corrugated Board Production Line Electrical Mill Roll Stand

  • High Light

    5 Ply Corrugated Board Production Line


    1400mm Corrugated Board Production Line

  • Corrugated Roller Diameter
  • Corrugated Roller Hardness
  • Corrugated Roller Material
    45# Steel
  • Corrugated Roller Shaft Hardness
  • Corrugated Roller Shaft Material
  • Corrugated Roller Shaft Surface Treatment
  • Corrugated Roller Surface Treatment
    Chrome Plating
  • Drive System
    AC Frequency Control
  • Max. Working Speed
  • Max. Working Thickness
  • Max. Working Width
  • Paper Type
    Kraft Paper, Corrugated Paper, Etc.
  • Paper Weight
  • Product Type
    Corrugated Board Production Line
  • Production Capacity
  • Place of Origin
  • Brand Name
  • Certification
    CE ISO
  • Model Number
  • Minimum Order Quantity
    1 set
  • Price
  • Delivery Time
    5 work days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    1 set per 30 days

1400mm 5 Ply Corrugated Board Production Line Electrical Mill Roll Stand

1400mm 5 Ply Corrugated Board Production Line Electrical Mill Roll Stand


1.Corrugated Board Production Line Description:

The Corrugated Board Production Line is a specialized machinery utilized for the production of corrugated board, a versatile packaging material composed of either paperboard or flute. The production process encompasses various stages, including cutting, gluing, and laminating, to ensure the highest quality output.

The Corrugated Board Production Line exhibits exceptional capabilities in terms of producing high-quality corrugated board at a rapid rate. The production line is generally comprised of four primary components, namely the cutting machine, gluing machine, laminating machine, and drying machine, each playing a vital role in the manufacturing process.

The production line can be operated either automatically or semi-automatically, with the primary control of the production process being executed through a state-of-the-art PLC and HMI control system. The Corrugated Board Production Line finds extensive applications in various industries.

2.Corrugated Board Production Line Specifications:

1 Max paper width 1400mm 2 Design speed 150m/min
3 5ply working speed 100-120m/min     ------------------------
4 Slitting accuracy ±1mm 5 Crosscut cutting accuracy ±1mm



The above speed indicators must reach: the production width is 1800mm, meet the following paper standards and ensure that the surface temperature of the heated parts of the equipment is 175℃.
Face paper index 100g/㎡--180g/㎡ Ring pressure index(N.m/g)≥8 (Moisture content8-10%)
Core paper index 80g/㎡--160g/㎡ Ring pressure index(N.m/g)≥5.5 (Moisture content8-10%)
Inside paper index 90g/㎡--160g/㎡ Ring pressure index(N.m/g)≥6 (Moisture content8-10%)
9 Flute combination
10 Steam requirements Maximum pressure16kg/cm2 Common pressure10-12kg/cm2 Dosage4000kg/Hr
11 electricity demand AC380V 50Hz 3PH Installed capacity≈150KW Common power≈110KW
12 Compressed air Maximum pressure9kg/cm2 Common pressure4-8kg/cm2 Dosage1m3/min
13 take up space ≈Lmin60m*Wmin10m*Hmin5m((Actually subject to the approved drawings provided by Party B)


3.Corrugated Board Production Line Feature Advantage:

  • High efficiency: The 5-ply corrugated board production line is designed to run at a high speed, allowing you to produce more boards per hour. This means you can meet the demands of your customers quickly and efficiently.
  • Consistent quality: The production line is equipped with advanced technology and precision tools to ensure that each board produced is of consistent quality. You can be confident that every board produced will meet your exacting standards.
  • High-capacity: The production line has a high capacity, allowing you to produce large quantities of boards at once. This means you can handle high-volume orders without compromising on quality.
  • Customizable: The production line is designed to be customized to meet your specific needs. You can choose the size, material, and thickness of the boards you want to produce, allowing you to create unique products for your customers.
  • Affordable: The production line is designed to be affordable for small and medium-sized businesses. You can invest in the latest technology without breaking the bank.
  • Easy to maintain: The production line is designed to be easy to maintain and operate. You can rely on the manufacturer's support to ensure that the equipment is running smoothly and efficiently.

4.Our Company

We are a professional supplier of corrugated machinery,including automatic high speed flex printer slot die cutters,corrugated board production lines,Rotary die cutters, carton staplers and two ply corrugated board production lines.Along with our development,we have set up our own factories. We are now enlarging our product area to testing equipment and other kinds of packaging machinery. We have rich experience and expertise in the field of corrugated machinery, and we can provide customized solutions for different customers’ needs. We are committed to delivering high quality products and services with competitive prices and timely delivery.

5.KSPACK Group

Hebei Jinguang Packing Machine Co.,Ltd

Cangzhou Kingsun IMP and EXP Co.,Ltd

Dongguang BaiYing Carton Machinery Co.,Ltd
