BYZ-A Series Automatic Box Folder Gluer Machine PLC Touch Screen
Product Details
Automatic Box Folder Gluer Machine
,PLC Box Folder Gluer Machine
BYZ-A Series Automatic Box Folder Gluer Machine PLC Touch Screen
1.Box Folder Gluer Machine Description:
Vacuum feeding section , glue and folding section ,counter and stacker section,plc digital speed control,remote speed control touch screen control system for easy and accurate operation.it can realize automatic feeding, automatic folding and gluing, automatic counting, and automatic stacking output,front and rear synchronous dual operation,average speed is 120m/min, the maximum speed can reach 160m/min,with order storage memory function,efficient energy conservation and environmental protection is our highest pursuit.
2.Box Folder Gluer Machine Spetification:
| Model | 2400 | 2500 |
| Max.Cardboard(mm) | 900×2200 | 1200×2500 |
| Min.Cardboard(mm) | 300×900 | 300×900 |
| Dimensions | L11000×W3000×H1600 | L12500×W3200×H1600 |
| Power Required | 12kw 380V 3phase 50HZ | 12kw380V 3phase 50HZ |
| Paperboard Thickness | 3 or 5 layer paperboard | |
| Control | PLC&TOUCH SCREEN | |
3.Box Folder Gluer Machine Main Part:
Feeding section
Vacuum suction feeding to feedwarping paperboard easily;
High quality electromagnetic clutchthe feeding part can be controlledindividually operation easily andreliable.
Glue Folding section:
Simpless structure and high reliability, glue quantity adjustable, cleaningeasily.stainless steel glue wheel adopted, long life saving glue costimported quality rubber belt feeding the paperboard and the usinglife can be longer;
With paperboard rectify device and creasing rectify device creaserwheel adjustable, suit for 2-8mm thick paperboard;
Second creasing struction can impress again the paperboardwhich was not creased well.
Counter Stacker section:
Stacking and counting are simple and reliable;
Digital control ,operation easily and reliable. No-stop put in data and automatic counting;
With rectification function;
Paperboard counting and put out by pneumatic,atable and quickly.
4.Our Company
We are a professional supplier of corrugated machinery,including automatic high speed flexo printer slotter die cutters,corrugated board production lines,Rotary die cutters, carton staplers and two ply corrugated board production lines.Along with our development,we have set up our own factories. We are now enlarging our product area to testing equipment and other kinds of packaging machinery.
5.FAQ
Q:Are you the trader or manufacturer?
A:We are the manufacturer with export qualification
Q:Do you make OEM?
A:Yes.here can do
Q:Where are your factory located in?
A:We are in Dongguang town,Cangzhou city,Hebei,china
Q:What is your business process?
A:Talking about clients requirements, confrim machines, make sales contract,pay for deposit,supplier arrange production,finish producing machines,buyer test machines,buyer pay for the balance payment,supplier delivery machine.
6.Our Service
Free Shipping Replacement Spare You just need to pay the freight
One To One Video Teaching We Provide Operation & Maintenance cd
-11 years experience
-Export to more than 150 countries
-Professional international sales more than 30 persons
-Professional sale team
technical team and after-sales service team
