Vacuum Transfer 4 Colors Corrugated Box Printing Machine With Die Cutter
Product Details
4 Colors Corrugated Box Printing Machine
,Vacuum Transfer Corrugated Box Printing Machine
Vacuum Transfer 4 Colors Corrugated Box Printing Machine With Die Cutter
1.Corrugated Box Printing Machine Description:
This Corrugated Box Printing Machine is an advanced equipment that can directly print out unique patterns and words on the corrugated board, and has been widely used in the packaging industry.
The Corrugated Box Printing Machine can not only print patterns, but also die-cut and slot the cardboard. Corrugated Box Printing Machine significantly improves production efficiency, reduces raw material costs, meets customers' personalized needs, and helps to improve the aesthetic and brand image of packaging.
It possesses the print, die-cutting, slotting memory function, which could return to Zero and Re-set automatically. PCLINK control network, MCGS software, Siemens low voltage electric appliance and host frequency conversion control, 30% electricity saving.
2.Corrugated Box Printing Machine Specifications:
| Model | Vacuum Transfer 4 Colors Corrugated Box Printing Machine With Die Cutter |
| Printer Color | Multi Color |
| Machine Size | Wall Board To Wall Board Size 2000/2200/2400/2600/2800/3000Mm |
| Machine Design Speed | Design Speed 200Pcs /Min |
| Work Speed | 180Pcs /Min |
| Machine Wall Board Size Mm | 60 |
| Gena Thickness (Mm) | 50-60 |
| Max Passing Paper Size (Mm) | 1200X2400 |
| Skip Paper Size (Mm) | 1400*2400Mm |
| Max Print Size (Mm) | 1200*2200mm |
| Thickness Of The Plate (Mm) | 3.2---7.2 |
| Board Thickness (Mm) | 3---12 |
| Board Print Accurate (Mm) | Print ±0.5/ Slot Open Accurate ±1.5 |
| Power At Production(Km) | 30 |
| Ultimate Capacity (Km) | 45 |
3.Feature Advantage:
Storage and adjustment of computer orders, faster order update and ease of operation.
Use high-precision instruments to make the machine wall panels and important parts to ensure the precision and quality of the machine parts. All the drive shafts and rollers are made of high quality steel with high precision dynamic balance and plated with solid chromium and polished on the grinding surface to greatly extending the service life, after long using, it still maintains the high topping precision.
The main machine transmission parts adopt the hand-free connection ring to eliminate the interval, suitable for long-term high speed printing.
The whole machine undergoes the spray lubrication and is equipped with engine oil automatic balance facilities.
Double axle slotting to configure whole machine production management computer control system and single axle slotting to configure whole machine production management computer control system.
Customer can choose use steel anilox roller or ceramic roller,the lines of the ceramic anilox can be chosed according to customer need.
4.Our Company:
We are a professional supplier of corrugated machinery,including automatic high speed flex printer slot die cutters,corrugated board production lines,Rotary die cutters, carton staplers and two ply corrugated board production lines.Along with our development,we have set up our own factories. We are now enlarging our product area to testing equipment and other kinds of packaging machinery. We have rich experience and expertise in the field of corrugated machinery, and we can provide customized solutions for different customers’ needs. We are committed to delivering high quality products and services with competitive prices and timely delivery.
5.FAQ:
Q:Are you the trader or manufacturer?
A:We are the manufacturer with export qualification
Q:Do you make OEM?
A:Yes.here can do
Q:Where are your factory located in?
A:We are in Dongguang town,CangZhou city,Hebei,china
Q:What is your business process?
A:Talking about clients requirements, confirm machines, make sales contract,pay for deposit,supplier arrange production,finish producing machines,buyer test machines,buyer pay for the balance payment,supplier delivery machine.
6.Our Service:
Free Shipping Replacement Spare You just need to pay the freight
One To One Video Teaching We Provide Operation & Maintenance CD
7.Corrugated Box Printing Machine Pictures:
-
