Automatic Box Folder Gluer Machine Corrugated Carton Packing Machine
Product Details
Gluer Machine Corrugated Carton
,Corrugated Carton Packing Machine
Automatic Box Folder Gluer Machine Corrugated Carton Packing Machine
Box Folder Gluer MachineProduct Description
Automatic carton folder gluer machine is the last procedure to make corrugated carton box - Folder and gluer the corrguated cardboard to finished carton box
Folder gluer machine mainly including three parts:
1) paper auto feeding part (Vacuum feeding )
2)glued folding part
3) Auto stacker part (with counter function )
Digital display is adjusted, PLC computer amplitude modulation, double frequency conversion synchronous operation, simple,reliable and precise control mode, automatic paper feeding, automatic glue folding, Automatic counting, automatic stacking output,average sticking speed of 150 m / min, maximum speed of 200 m / min, high efficiency, energy saving and environmental protection,is our highest pursuit.
Box Folder Gluer Machine Feeding section :
1.vacuum suction feeding to feed warping paperboard easily
2. quality electromagnetic cluth and brak adopted ,feeding section controled independent ,operation easily
3. scorer wheel adjustable ,suit for 2-8mm thick paperboard
4. second creasing struction can impress again the paperboard which was not creased well
Box Folder Gluer Machine Glue and folding section:
1.Simpless structure and high reliablity ,glue quantity adjustable ,cleaning easily ,
2.Stainless steel glue wheel adopted ,long life and saving glue cost ,
3.Imported quality rubber belt adopted ,automatic folding
4.With paperboard rectify device and creasing rectify device
Box Folder Gluer Machine Counter and stacker section:
1.Stacking and counting are simple and reliable
2.Digital control operation easily and reliable ,no stop put in date and automatic counting
3.With rectification function
4.Paperboard counting and put out by pneumatic stable and quickly
Box Folder Gluer Machine Specification
|
Type |
KS-QZD2000 |
KS-QZD2400 |
KS-QZD2800 |
|
Max cardboard |
1000*1900mm |
1000*2300mm |
1000*2650mm |
|
Min cardboard |
170*430mm |
300*720mm |
300*700mm |
|
Installation area |
2400*1350mm |
2800*1550mm |
3400*1550mm |
|
Power required |
11.5KW |
11.5KW |
11.5KW |
Our Company
We are a professional supplier of corrugated machinery,including automatic high speed flexo printer slotter die cutters,corrugated board production lines,Rotary die cutters, carton staplers and two ply corrugated board production lines.Along with our development,we have set up our own factories. We are now enlarging our product area to testing equipment and other kinds of packaging machinery.
FAQ
|
Q |
A |
|
Are you the trader or manufacturer? |
We are the manufacturer with export qualification |
|
Do you make oem? |
Yes.here can do |
|
5.where are your factory located in? |
We are in dongguang town,cangzhou city,hebei,china |
|
What is your business process? |
Talking about clients requirements, confrim machines, make sales contract,pay for deposit,supplier arrange production,finish producing machines,buyer test machines,buyer pay for the balance payment,supplier delivery machine. |
After Sales Service
Free Shipping Replacement Spare You just need to pay the freight
One To One Video Teaching We Provide Operation & Maintenance cd
-11 years experience
-Export to more than 150 countries
-Professional international sales more than 30 persons
-Professional sale team
technical team and after-sales service team
