Corrugated Carton Paper Pizza Box Making Machine With Slotting And Die Cutting
Product Details
high speed flexographic printing machine
,carton box making machine
Corrugated Carton Paper Pizza Box Making Machine with Slotting and Die Cutting
1.Box making machine introduction
Box making machine is used to produce pizza boxes , that is made from corrugated paper board . This type of box making machine has the character of non-regular shape paper board . We need to use the die cutting method to cut the corner or holes of the paper board.
Box making machine also used produced fruit boxes , that is made from corrugated paper board . This type of box making machine has the character of regular shape paper box . Operation it very easy and convinient .
2. Machine technical parameter
| Size | 2400 mm ( width ) or as your requirement |
| Roller diameter | 400 mm |
| Max feeder paper size | 1200*2400 mm |
| Min feeder paper size | 300*500 mm |
| Max printing area | 1200*2200 mm |
| Design speed | 100 pcs / min |
| Economic speed | 80 pcs / min |
| Standard printing block thickness | 7.2mm |
| Max motor | 7.5KW 2 color,11KW 3 color , 15KW 4 color |
| Air pump power | 7.5 KW |
| 13 accurate of print | +-0.5 |
| Die cut accurate | +-1mm |
2. Machine function for Die cutter
The die cutter roller (down roller)
1) outer diameter is: 435mm . (not including cutting die)
2) cast steel material, surface grinding, hard chromium plating.
3) balance correction, increase the running stability.
4) die cutter fixed screw holes spacing gap is : 100 * 100 mm.
5) apply to die cutting height 25.4 mm.
6) die cutting thickness is :16 to 18 mm (three layer board), 13-15 mm (five layer board).
Rubber gasket roller (up roller)
1) the outer wall is: 434.9mm.
2) cast steel material, surface grinding, hard chromium plating.
3) balance correction, increase the running stability.
4) manual adjustments with die cutting roller gap.
5) rubber gasket thickness10 mm, ( outside diameter is: 454.2mm ), width is 230 mm.
Lateral movement, repair device:
1) mechanical type horizontal 40 mm, move device, die-cutting equalizer automatic compensation linear speed , can make the die cutting rubber gasket even wear, prolong service life.
2) repair adopt electric repair device, improve the rubber gasket repeat utilization rate, can repair 3-4 times.
3) die cutting roller automatic pneumatic separation device, reduce wear rubber gasket , thus improve the service life.
Free plate fixture :
1) die cutting fast swap multi-function at an organic whole, conventional carton box without templates.
2) with a thin blade slotter the effect, thus saving the cost of production.
4. Machine Photos
-
