Semi Automatic Corrugated Box Printing Machine , Carton Paper Flexo Printing Machine for Packing Industry
Product Details
two color flexo printing machine
,carton box making machine
Semi Automatic Carton Paper Flexo Printing Machine for Packing Industry
1. Enquiry Guide
a. Machine work speed : 40-50 pcs/min as machine model JGY-1
b. Machine color : you can choose 1.2.3.4 color
c. Machine size : 900*1800 ,900*2000,900*2200 ,900*2400,900*2600,900*2800
1200*1800,1200*2000,1200*2200,1200*2400,1200*2600,1200*2800
1450*1800,1450*2000,1450*2200,1450*2400,1450*2600,1450*2800
1600*1800,1600*2000,1600*2200,1600*2400,1600*2600,1600*2800
d. Box type : normal shape box used by slotter
abnormal shape box used by die cutter
e. If choose slotter and die cutter both , you can choose seperate in 2 groups ,as well as choose slotter
and die cutter combined in one group .
Inform us a .b.c.d.e exact requirement , we will send you exact and good machine quotation .
2.Technical Parameter
| Model | JGY-1 (1200 ) | JGY-1 (1450) | JGY-1 (1650 ) |
| Diameter of roller | 400mm | 490mm | 530mm |
| The max work speed | 40-50 pcs /min |
40-50 pcs /min
|
40-50 pcs /min |
| The max feeding size | 1200*(2200-2800)mm | 1450*(2200-2800)mm | 1650*(2200-2800)mm |
| Slot min feeding size | 330*600mm | 350*600mm | 380*600mm |
| Effective printing size | 1200*(2000-2600) mm | 1450*(2000-2600)mm | 1650*(2000-2600)mm |
| The effective thickness | 3/5/7 ply(2-12mm) | 3/5/7 ply(2-12mm) | 3/5/7 ply(2-12mm) |
| The max depth of slot | 314 | 314 | 314 |
3.Mainly Function and Using
The machine is the corrugated cardboard pattern double color water ink protruding printing , roll line ,separate paperboard ,cut corner ,open slot ,more functions compound equipment.
4.Machine Photo
-
