Cold Flute Laminator Machine Glue Paper Board 360mm * 360mm Min Laminator Size
Product Details
vacuum laminating machine
,laminate pressing machine
TMB1300 semiautomatic Cold Glue Paper Board Flute Laminator Machine
1.The machine auto feeding corrugated board
2.,manual feeding above paper ,
3.above paper can adjust front and behind,never go ahead ,match with the adjust the speed..
4.machine is used to paste the color-printing surface paper together with the bottom paper (cardboard or corrugated sheet) accurately Suitable for lamination of corrugated cardboard(A/B/C/D/E/F) to paperboard
(350grams) ,and paperboard 175-500grmas to grey board above 350g
5.Automatic feeding of bottom sheet and normal front feeding of top sheet With flexible front gauge positioning to control the laminating precision. Stepless timing, novelty and beauty,easy to clean ,easy operation and high laminating precision.
6.New equipment for producing the high quality cardboard, makes the cardboard more striking, nice and high intensity.
7.Used widely for packing food, wine bottle, electric appliance and light industry products.
| Model | TMB | TMB | TMB |
| Max laminator size | 1300mm×1100mm | 1450mm×1100mm | 1600mm×1100mm |
| Min laminator size | 360mm×360mm | 360mm×360mm | 360mm×360mm |
| Speed | 0-60m/min | 0-60m/min | 0-60m/min |
| Power | 7kw | 7kw | 7kw |
| Machine size | 8.8m×1.95m×1.5m | 8.8m×2.1m×1.5m | 8.8m×2.25m×1.5m |
| Weight | 3T | 3.2T | 3.5T |
Machine Picture:
-
