Semi Auto Thin Blade Slitter Scorer Machine For Corrugated Paper
Product Details
slitter cutter creaser
,paper scoring machine
Semi Auto Thin Blade Slitter Scorer Machine For Corrugated Paper
1.Thin blade slitter scorer machine function
1) Slitting corrugated paperboard to several narrow pieces
2) Cresing the horizontal line for corrugated carton box
2.Characters
1)Slitting part: adopt high quality tungsten steel blade, sharp and long work-life, slice more tidy, non-pressing and non-burr.
2)Adopt 8 shafts design, two shafts in front and back of the slitter, can minimize the length of paperboard machining to 260mm.
3)shafts with front-scoring feeding,back double rubber rollers for paper leading, running more steady.
4)Scoring part: adopt 5 points scoring, scoring distance in-phase adjust, blazonry and easy to bend the carton sheet.
5)Grinding part: adopt automatic and manual two kinds pneumatic
grinding type, it could be grinding when working, improve work efficiency.
3.Detailed technical paramaters for 2000mm thin blade slitter machine
| Item | Character |
| Effective width | 1800mm |
| Speed | 140m/min |
| Power | 4KW |
| Min slitting spacing | 120mm |
| Min score spacing | 30mm |
| Machine rough size |
2640*770*1350mm |
4.Free spare parts and Thin blade slitter machine picture
-
