Plc Corrugated 7.5kw Multi Color Flexo Printing Machine

Plc Corrugated 7.5kw Multi Color Flexo Printing Machine

  • High Light

    Corrugated Multi Color Flexo Printing Machine

    ,

    7.5kw Multi Color Flexo Printing Machine

    ,

    plc multicolor flexo printing machine

  • Machine Name
    22020 Hot Sell Machine Corrugated Flexo Printing Corrugated Carton Box Machine Price
  • Weight
    8T
  • Size
    900*2400mm Or Customized
  • Voltage
    220V
  • Feature
    PLC Control
  • Power
    7.5kw
  • Place of Origin
    China
  • Brand Name
    Kingsun
  • Certification
    CE
  • Model Number
    KSJ
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiate
  • Packaging Details
    Packing them in plastic wrap before putting them in wooden cases
  • Delivery Time
    20 work days
  • Payment Terms
    L/C, T/T, Western Union
  • Supply Ability
    5 set 40per days

Plc Corrugated 7.5kw Multi Color Flexo Printing Machine

2020 hot sell machine corrugated flexo printing corrugated carton box machine price



This machine can make all kinds of corrugated carton box , standard corrugated carton box such as fruit box , logistics box ,daily necessities carton box , household appliances box , special corrugated carton box such as pizza box and other customized carton box .
This machine real working speed can be 200pcs per min , fully PLC control


1)Main Features

1) The edge-leader feeding system adopt light pressure type, It reduce friction between paperboard and the platform

2) Fully automatic PLC control , adjust feeder , printer , slotter , die cutter by computer

3)All printer units with ceramic anilox rollers and doctor blades - makes the printing part with high precision

4)Our rubber mat for die cutting mould use Maxdura brand ,and die cutter roller thickness up to 15mm .

5)Very high speed - working speed can reach up to 200pcs /min

6) Electric button control machine from the alarm bell, continuous ringing warning, to ensure the safety of workers



2)Feeding part

1.up roller use the soft rubber shaft ,so when feed the board ensure the not broken the board , wearing rubber shaft , make the balance correct ,keep the paper feed steady and accurate. 2.The lower feed roller with embossing roller diameter ¢ 175 mm, seamless steel pipe, embossed hard chrome plating. 3.feeding roller cross slider-type dial dial manually adjust the adjustment range of 0 ~ 12 mm. Adjustment does not affect the gear gap, to ensure transmission accuracy.



3)Printer slotter die cutter part


1.Printer unit ,printing color on corrugated paperboard , it can be 1 color , 2 color , 3 color , 4 color , 5 color . this machine is 2 color
2. slotter unit , for standard box cutting , box size is adjustable
3.Die cutter unit , for special box cutting , install different die cutting mould can make different design carton box
4.slotter and die cutter can combined in same unit , machine price is better



Name of parameter KSJ-900 KSJ-1200 KSJ-1400
Color Group Everything can be quipped according to users’ needs
Printing Paper A,B,C,A/B,B/C and A/B/C Corrugated Cardboard(Maximum gap 11mm)
Production Speed 180 Pieces/min 170 Pieces/min 160 Pieces/min
Economic Speed 170 Pieces/min 160 Pieces/min 150 Pieces/min
Max.Paper Sizes

900x1800/2000

2200/2400/2600mm

1200x1800/2000

2200/2400/2600mm

1400x1800/2000

2200/2400/2600mm

Min.Paper Sizes

Positive knife

Negative knife



300x640mm

300x720mm



350x720mm

350x740mm



400x720mm

400x740mm

Max.Printing Sizes

900x1600/1800

2000/2200/2400mm

1200x1600/1800

2000/2200/2400mm

1400x1600/1800

2000/2200/2400mm

Max.Die-cutting Size

900x1700/1900

2100/2300/2500mm

1200x1700/1900

2100/2300/2500mm

1400x1700/1900

2100/2300/2500mm

Standard Printing Plate Thickness 7.2mm
Slot Width x Max.depth

7mmx220mm 7mmx300mm 7mmx350mm

(Number of blade and slot depth may be added)

Min.Slot Space

Positive knife

Negative knife



150*150*150*150mm

250*90*250*90mm



170*170*170*170mm

260*90*260*90mm



170*170*170*170mm

260*90*260*90mm

Printing Roller Dia 300mm 408mm 480mm
