Chain Feed Corrugated Box Die Cutting Machine 2050x1350mm Rotary Die Cutter Machine

Chain Feed Corrugated Box Die Cutting Machine 2050x1350mm rotary die cutter machine

We are excited to introduce our latest innovation – KS Series Rotary Die Cutter. This product is designed to laminate a wide range of corrugated materials and various types of specialized package layouts, providing superior efficiency, energy saving, and safety measures.
The KS Series is grounded in technology, providing users with a seamless blend of precision, sustainability and dependability. Featuring components imported from Europe, this tool has a long operational life of up to ten million die-cutting operations, which is derived from its premium polyurethane backing (anivil cover). In addition, it comes with an automatic line speed compensation function, ensuring uniform fraying of the blanket post molding, maintaining a consistent cardboard size. A reliable mechanical tonal relief roller servo system ensures extended use up to three times longer than conventional counterparts.
This innovative feeding mechanism combines a self-locking linkage mechanism (chain feeding system) for ease of use. Its robust nature ensures durability despite frequent handling.
In summary, the KS Series Rotary Die Cutter supersedes traditional offerings, offering unparalleled performance and value. With outstanding quality, reliability and longevity, it is the perfect choice for any professional who needs a cutting solution for a wide spectrum of applications.

Paper feed section
1.manual chain feed, complete slot, cut angle, crease, punching one time.
2.the paper feed speed 4000 pcs per hour, die cutting accuracy ± 1mm.
3.phase phase motor with electric adjustment structure, start and stop are quickly adjusted.
4.electroplating feed paper wheel, to prevent crushing cardboard, increase the accuracy of paper feed.
5.chain trolly with high-strength engineering plastics, impatient tone low, durable.


Electrical department
1, the main motor electromagnetic adjust speed, save power.
2, ahead and back control panel , easy to operate.
3, the whole by light, electricity, air joint control system.
4,whole electrical accessories are brand-name manufacturers products.

Die cutting
1, die-cutting roller for high-quality steel, wall thickness 30mm, balanced correction, hard chrome plated
2, wall panels for high-quality cast iron material, wall thickness 50mm, large-scale processing center production.
3, soft roller automatic grinding mechanism to improve the re-use of anil cover, grinding 3-4 times.
4, the line speed automatic compensation to ensure that each batch of carton die cutting size exactly the same.
5, imported polyurethane soft cut sets, easy installation, die cutting 12 million times.
6, cam-type soft roller around the horizontal movement of 40mm, anil cover wear evenly.
7, lubrication system oil-immersed lubrication, simple and efficient.
